TracoPower TES 3-2411WI DC/DC converter (SMD) 24 V DC 5 V DC 600 mA 3 W No. of outputs: 1 x Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 35.29 / piece)
€ 35.29
plus VAT.
Only 5 Piece(s) available
Technical specifications
- Product type
DC/DC converter (SMD)
- Type
TES 3-2411WI
- Nominal voltage
24 V DC
- Min. input voltage
21.6 V DC
- Input voltage (max.)
26.4 V DC
- No. of outputs
1 x
- Output voltages
5 V DC
- Max. output current
600 mA
- Output current (max.) - rounded
600 mA
- Efficiency (max.)
83 %
3 W
- Insulation voltage
1500 V DC
- Enclosure
SMD
- Connection
SMD
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
85 °C
- Dim
(L x W x H) 32.3 x 18.8 x 10.2 mm
- Height
10.2 mm
- Length
32.3 mm
- Width
18.8 mm
- Output voltage (max.)
5 V DC
- Output voltage (min.)
5 V DC
- Weight
8.8 g
- Content
1 pc(s)
- Type
TES 3-2411WI
Documents & Downloads
Datasheet
Datasheet 1510251 TracoPower TES 3-2411WI DC/DC converter (SMD) 24 V DC 5 V DC 600 mA 3 W No. of outputs: 1 x Content 1 pc(s)
Datasheet 1510251 TracoPower TES 3-2411WI DC/DC converter (SMD) 24 V DC 5 V DC 600 mA 3 W No. of outputs: 1 x Content 1 pc(s)
Warranty Terms
Warranty Terms 1510251 TracoPower TES 3-2411WI DC/DC converter (SMD) 24 V DC 5 V DC 600 mA 3 W No. of outputs: 1 x Content 1 pc(s)
Description
Compact SMD casing, 4:1 input range, input/output insulation 1500 V/DC, input filter according to EN 55022, class A. Suitable for lead-free soldering process after IPC/JEDEC J-STD-020D.
