TracoPower THB 10-4823 DC/DC converter (print) 48 V DC 15 V DC, -15 V DC 333 mA 10 W No. of outputs: 2 x Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Minimum order quantity: 10
Total (€ 68.90 / piece)
€ 689.00
plus VAT.
14-day return policy included
Technical specifications
- Product type
DC/DC converter (print)
- Type
THB 10-4823
- Nominal voltage
48 V DC
- Min. input voltage
36 V DC
- Input voltage (max.)
75 V DC
- No. of outputs
2 x
- Output voltages
15 V DC
-15 V DC
- Max. output current
333 mA
- Output current (max.) - rounded
333 mA
- Efficiency (max.)
82 %
10 W
- Insulation voltage
4000 V AC
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
75 °C
- Dim
(L x W x H) 25.4 x 50.8 x 17.08 mm
- Height
17.08 mm
- Length
25.4 mm
- Width
50.8 mm
- Output voltage (max.)
15 V DC
-15 V DC
- Output voltage (min.)
15 V DC
-15 V DC
- Weight
24.5 g
- Content
1 pc(s)
Compliance & Certifications
Certified by EU Garan
Documents & Downloads
Datasheet
Datasheet 3370736 TracoPower THB 10-4823 DC/DC converter (print) 48 V DC 15 V DC, -15 V DC 333 mA 10 W No. of outputs: 2 x Content 1 pc(s)
Datasheet 3370736 TracoPower THB 10-4823 DC/DC converter (print) 48 V DC 15 V DC, -15 V DC 333 mA 10 W No. of outputs: 2 x Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3370736 TracoPower THB 10-4823 DC/DC converter (print) 48 V DC 15 V DC, -15 V DC 333 mA 10 W No. of outputs: 2 x Content 1 pc(s)
Warranty Terms
Warranty Terms 3370736 TracoPower THB 10-4823 DC/DC converter (print) 48 V DC 15 V DC, -15 V DC 333 mA 10 W No. of outputs: 2 x Content 1 pc(s)
Description
E/A-insulation 4000 V/AC designed for 300 V/AC operating voltage, 2 x MOOP medical standard according to IEC/EN 60601-1, 3rd edition, 2:1 input range, input filter according to EN 55022, class A, short-circuit proof.
