TracoPower THB 6-4812 DC/DC converter (print) 48 V DC 12 V DC 500 mA 6 W No. of outputs: 1 x Content 1 pc(s)
Part number:
Item no:
Datasheet (PDF)
Sales and shipping:
Number
Minimum order quantity: 10
Total (€ 55.45 / piece)
€
Technical specifications
- Product type
DC/DC converter (print)
- Type
THB 6-4812
- Nominal voltage
48 V DC
- Min. input voltage
36 V DC
- Input voltage (max.)
75 V DC
- No. of outputs
1 x
- Output voltages
12 V DC
- Max. output current
500 mA
- Output current (max.) - rounded
500 mA
- Efficiency (max.)
80 %
6 W
- Insulation voltage
3000 V AC
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
71 °C
- Dim
(L x W x H) 31.8 x 20.3 x 15.8 mm
- Height
15.8 mm
- Length
31.8 mm
- Width
20.3 mm
- Output voltage (max.)
12 V DC
- Output voltage (min.)
12 V DC
- Weight
18 g
- Content
1 pc(s)
Documents & Downloads
Datasheet
Datasheet 3370756 TracoPower THB 6-4812 DC/DC converter (print) 48 V DC 12 V DC 500 mA 6 W No. of outputs: 1 x Content 1 pc(s)
Datasheet 3370756 TracoPower THB 6-4812 DC/DC converter (print) 48 V DC 12 V DC 500 mA 6 W No. of outputs: 1 x Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3370756 TracoPower THB 6-4812 DC/DC converter (print) 48 V DC 12 V DC 500 mA 6 W No. of outputs: 1 x Content 1 pc(s)
Warranty Terms
Warranty Terms 3370756 TracoPower THB 6-4812 DC/DC converter (print) 48 V DC 12 V DC 500 mA 6 W No. of outputs: 1 x Content 1 pc(s)
Description
E/A-insulation 3000 VAC designed for 1000 V/AC operating voltage. Approval according to medical standard UL 60601-1 and IEC/EN 60601-1, 3rd edition, 2 x MOOP. 2:1 input range, low leakage current, short-circuit proof.
