TracoPower THD 12-2422 DC/DC converter (print) 24 V DC 12 V DC, -12 V DC 500 mA 12 W No. of outputs: 2 x Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 40.33 / piece)
€ 40.33
plus VAT.
Only 5 Piece(s) available
Highlights & Details
TracoPower THD 12-2422 DC/DC converter (print) 24 V DC 12 V DC, -12 V DC 500 mA 12 W No. of outputs: 2 x Content 1 pc(s)
- 3-year guarantee
Technical specifications
- Ripple: (20 MHz bandwidth) 100 mVpp
- Power control ± 0.5%
- Load regulation (%): (Single) ± 1.0%/(Dual) ±2.0%
- Product type
DC/DC converter (print)
- Type
THD 12-2422
- Nominal voltage
24 V DC
- Min. input voltage
18 V DC
- Input voltage (max.)
36 V DC
- No. of outputs
2 x
- Output voltages
12 V DC
-12 V DC
- Max. output current
500 mA
- Output current (max.) - rounded
500 mA
- Efficiency (max.)
88 %
12 W
- Insulation voltage
1500 V DC
- Enclosure
DIL 24
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
85 °C
- Content
1 pc(s)
12 W
- Output voltage
12 V DC
- Output current (details)
±500 mA
- Type
THD 12 Series
- Operating temperature
(above 60 ºC power reduction 2.5 %/K) -40 - +85 ºC
- Mains control
max ±0.5 %
Documents & Downloads
Datasheet
Datasheet 154640 TracoPower THD 12-2422 DC/DC converter (print) 24 V DC 12 V DC, -12 V DC 500 mA 12 W No. of outputs: 2 x Content 1 pc(s)
Datasheet 154640 TracoPower THD 12-2422 DC/DC converter (print) 24 V DC 12 V DC, -12 V DC 500 mA 12 W No. of outputs: 2 x Content 1 pc(s)
Warranty Terms
Warranty Terms 154640 TracoPower THD 12-2422 DC/DC converter (print) 24 V DC 12 V DC, -12 V DC 500 mA 12 W No. of outputs: 2 x Content 1 pc(s)
Description
Small 15 W converter in plastic casing. Wide 2:1 input ranges, protected against permanent short circuit, industry-standard pinning, remote on/off.
Hints
Approvals: UL/cUL 60950, EN 60950 and IEC 60950.
