TracoPower THL 10-1223 DC/DC converter (print) 12 V DC 15 V DC, -15 V DC 100 mA 10 W No. of outputs: 2 x Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Minimum order quantity: 10
Total (€ 35.29 / piece)
€ 352.90
plus VAT.
Technical specifications
- Product type
DC/DC converter (print)
- Type
THL 10-1223
- Nominal voltage
12 V DC
- Min. input voltage
9 V DC
- Input voltage (max.)
18 V DC
- No. of outputs
2 x
- Output voltages
15 V DC
-15 V DC
- Max. output current
100 mA
- Output current (max.) - rounded
100 mA
- Efficiency (max.)
87 %
10 W
- Insulation voltage
1500 V DC
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
80 °C
- Dim
(L x W x H) 25.4 x 25.4 x 20.32 mm
- Height
20.32 mm
- Length
25.4 mm
- Width
25.4 mm
- Output voltage (max.)
15 V DC
-15 V DC
- Output voltage (min.)
15 V DC
-15 V DC
- Weight
15 g
- Content
1 pc(s)
Documents & Downloads
Datasheet
Datasheet 3370866 TracoPower THL 10-1223 DC/DC converter (print) 12 V DC 15 V DC, -15 V DC 100 mA 10 W No. of outputs: 2 x Content 1 pc(s)
Datasheet 3370866 TracoPower THL 10-1223 DC/DC converter (print) 12 V DC 15 V DC, -15 V DC 100 mA 10 W No. of outputs: 2 x Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3370866 TracoPower THL 10-1223 DC/DC converter (print) 12 V DC 15 V DC, -15 V DC 100 mA 10 W No. of outputs: 2 x Content 1 pc(s)
Warranty Terms
Warranty Terms 3370866 TracoPower THL 10-1223 DC/DC converter (print) 12 V DC 15 V DC, -15 V DC 100 mA 10 W No. of outputs: 2 x Content 1 pc(s)
Description
10 Watt in the 25.4mm x 25.4mm metal housing, 2:1 input range, input/output insulation voltage 1500 V/DC, input filter according to EN 55022, class A.
