TracoPower THL 3-2410WI DC/DC converter (print) 24 V DC 3.3 V DC 600 mA 3 W No. of outputs: 1 x Content 1 pc(s)
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
10
-
€ 25.20
30
4% = € 1.09
€ 24.11
Volume discounts vary depending on the seller
You save € 0.00
Number
Minimum order quantity: 10
Total (€ 25.20 / piece)
€ 252.00
plus VAT.
14-day return policy included
Technical specifications
- Product type
DC/DC converter (print)
- Type
THL 3-2410WI
- Nominal voltage
24 V DC
- Min. input voltage
9 V DC
- Input voltage (max.)
36 V DC
- No. of outputs
1 x
- Output voltages
3.3 V DC
- Max. output current
600 mA
- Output current (max.) - rounded
600 mA
- Efficiency (max.)
75 %
3 W
- Insulation voltage
1500 V DC
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
85 °C
- Dim
(L x W x H) 13.7 x 23.8 x 12.1 mm
- Height
12.1 mm
- Length
13.7 mm
- Width
23.8 mm
- Output voltage (max.)
3.3 V DC
- Output voltage (min.)
3.3 V DC
- Weight
5.4 g
- Content
1 pc(s)
Compliance & Certifications
Certified by EU Garan
Documents & Downloads
Datasheet
Datasheet 3370939 TracoPower THL 3-2410WI DC/DC converter (print) 24 V DC 3.3 V DC 600 mA 3 W No. of outputs: 1 x Content 1 pc(s)
Datasheet 3370939 TracoPower THL 3-2410WI DC/DC converter (print) 24 V DC 3.3 V DC 600 mA 3 W No. of outputs: 1 x Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3370939 TracoPower THL 3-2410WI DC/DC converter (print) 24 V DC 3.3 V DC 600 mA 3 W No. of outputs: 1 x Content 1 pc(s)
Warranty Terms
Warranty Terms 3370939 TracoPower THL 3-2410WI DC/DC converter (print) 24 V DC 3.3 V DC 600 mA 3 W No. of outputs: 1 x Content 1 pc(s)
Description
Compact design in the DIL 16 casing, 4:1 input range, input/output insulation 1500 V/DC, short-circuit proof, external on/off, input filter according to EN 55022, class A.
