TracoPower THL 3-2410WISM DC/DC converter (SMD) 24 V DC 3.3 V DC 600 mA 3 W No. of outputs: 1 x Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 21.00
3
4% = € 0.92
€ 20.08
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 21.00 / piece)
€ 21.00
plus VAT.
Technical specifications
- Product type
DC/DC converter (SMD)
- Type
THL 3-2410WISM
- Nominal voltage
24 V DC
- Min. input voltage
9 V DC
- Input voltage (max.)
36 V DC
- No. of outputs
1 x
- Output voltages
3.3 V DC
- Max. output current
600 mA
- Output current (max.) - rounded
600 mA
- Efficiency (max.)
75 %
3 W
- Insulation voltage
1500 V DC
- Enclosure
SMD
- Connection
SMD
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
85 °C
- Dim
(L x W x H) 18.1 x 24 x 8 mm
- Height
8 mm
- Length
18.1 mm
- Width
24 mm
- Output voltage (max.)
3.3 V DC
- Output voltage (min.)
3.3 V DC
- Weight
5.4 g
- Content
1 pc(s)
- Type
3-2410 THL WISM
Documents & Downloads
Datasheet
Datasheet 1510559 TracoPower THL 3-2410WISM DC/DC converter (SMD) 24 V DC 3.3 V DC 600 mA 3 W No. of outputs: 1 x Content 1 pc(s)
Datasheet 1510559 TracoPower THL 3-2410WISM DC/DC converter (SMD) 24 V DC 3.3 V DC 600 mA 3 W No. of outputs: 1 x Content 1 pc(s)
Warranty Terms
Warranty Terms 1510559 TracoPower THL 3-2410WISM DC/DC converter (SMD) 24 V DC 3.3 V DC 600 mA 3 W No. of outputs: 1 x Content 1 pc(s)
Description
Compact design in the SMD casing, 4:1 input range, input/output insulation 1500 V/DC, suitable for lead-free reflow soldering process, MSL 2a, short-circuit proof, external on/off, input filter according to EN 55022, class A.
