TracoPower THL 6-2423WISM DC/DC converter (SMD) 24 V DC 15 V DC, -15 V DC 200 mA 6 W No. of outputs: 2 x Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 34.45 / piece)
€ 34.45
plus VAT.
Technical specifications
- Product type
DC/DC converter (SMD)
- Type
THL 6-2423WISM
- Nominal voltage
24 V DC
- Min. input voltage
9 V DC
- Input voltage (max.)
36 V DC
- No. of outputs
2 x
- Output voltages
15 V DC
-15 V DC
- Max. output current
200 mA
- Output current (max.) - rounded
200 mA
- Efficiency (max.)
83 %
6 W
- Insulation voltage
1500 V DC
- Enclosure
SMD
- Connection
SMD
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
75 °C
- Dim
(L x W x H) 25.4 x 22 x 10.05 mm
- Height
10.05 mm
- Length
25.4 mm
- Width
22 mm
- Output voltage (max.)
15 V DC
-15 V DC
- Output voltage (min.)
15 V DC
-15 V DC
- Weight
78 g
- Content
1 pc(s)
- Type
6-2423 THL WISM
Documents & Downloads
Datasheet
Datasheet 1510597 TracoPower THL 6-2423WISM DC/DC converter (SMD) 24 V DC 15 V DC, -15 V DC 200 mA 6 W No. of outputs: 2 x Content 1 pc(s)
Datasheet 1510597 TracoPower THL 6-2423WISM DC/DC converter (SMD) 24 V DC 15 V DC, -15 V DC 200 mA 6 W No. of outputs: 2 x Content 1 pc(s)
Warranty Terms
Warranty Terms 1510597 TracoPower THL 6-2423WISM DC/DC converter (SMD) 24 V DC 15 V DC, -15 V DC 200 mA 6 W No. of outputs: 2 x Content 1 pc(s)
Description
Compact design in the SMD casing, 4:1 input range, input/output insulation 1500 V/DC, short-circuit protection, input filter according to EN 55022, class A, suitable for lead-free reflow soldering process.
