TracoPower THM 15-2415WI DC/DC converter (print) 24 V DC 625 mA 15 W No. of outputs: 1 x Content 1 pc(s)
Part number:
Item no:
Datasheet (PDF)
Number
Minimum order quantity: 10
Total (€ 70.58 / piece)
€ 705.80
plus VAT.
14-day return policy included
Technical specifications
- Product type
DC/DC converter (print)
- Type
THM 15-2415WI
- Nominal voltage
24 V DC
- Min. input voltage
9 V DC
- Input voltage (max.)
36 V DC
- No. of outputs
1 x
- Max. output current
625 mA
- Output current (max.) - rounded
625 mA
- Efficiency (max.)
88 %
15 W
- Insulation voltage
5000 V AC
- Enclosure
DIP 10 (1/8 brick)
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
+85 °C
- Dim
(L x W x H) 40.6 x 25.4 x 15.8 mm
- Height
15.8 mm
- Length
40.6 mm
- Width
25.4 mm
- Output voltage (max.)
24 V DC
- Content
1 pc(s)
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3371665 TracoPower THM 15-2415WI DC/DC converter (print) 24 V DC 625 mA 15 W No. of outputs: 1 x Content 1 pc(s)
Datasheet 3371665 TracoPower THM 15-2415WI DC/DC converter (print) 24 V DC 625 mA 15 W No. of outputs: 1 x Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3371665 TracoPower THM 15-2415WI DC/DC converter (print) 24 V DC 625 mA 15 W No. of outputs: 1 x Content 1 pc(s)
Warranty Terms
Warranty Terms 3371665 TracoPower THM 15-2415WI DC/DC converter (print) 24 V DC 625 mA 15 W No. of outputs: 1 x Content 1 pc(s)
