TracoPower THM 3-4822 DC/DC converter (print) 125 mA 3 W No. of outputs: 2 x Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Minimum order quantity: 10
Total (€ 45.37 / piece)
€ 453.70
plus VAT.
14-day return policy included
Technical specifications
- Product type
DC/DC converter (print)
- Type
THM 3-4822
- Min. input voltage
36 V DC
- Input voltage (max.)
75 V DC
- No. of outputs
2 x
- Max. output current
125 mA
- Output current (max.) - rounded
125 mA
- Efficiency (max.)
86 %
3 W
- Insulation voltage
5000 V AC
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
90 °C
- Dim
(L x W x H) 31.80 x 20.30 x 10.20 mm
- Height
10.20 mm
- Length
31.80 mm
- Width
20.30 mm
- RoHS-compliant
Yes
- Output voltage (max.)
12 V DC
-12 V DC
- Output voltage (min.)
12 V DC
-12 V DC
- Weight
14 g
- Content
1 pc(s)
