TracoPower THM 60-4812WI DC/DC converter (print) 48 V DC 12 V DC 5 A 60 W No. of outputs: 1 x Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Minimum order quantity: 5
Total (€ 126.04 / piece)
€ 630.20
plus VAT.
14-day return policy included
Technical specifications
- Product type
DC/DC converter (print)
- Type
THM 60-4812WI
- Nominal voltage
48 V DC
- Min. input voltage
18 V DC
- Input voltage (max.)
36 V DC
- No. of outputs
1 x
- Output voltages
12 V DC
- Max. output current
5 A
- Output current (max.) - rounded
5 A
60 W
- Connection
Soldering
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
+75 °C
- Dim
(L x W x H) 50.80 x 36.80 x 12.70 mm
- Height
12.70 mm
- Length
50.80 mm
- Width
36.80 mm
- RoHS-compliant
Yes
- Weight
51
- Content
1 pc(s)
