TracoPower THN 15-2411 DC/DC converter (print) 24 V DC 5 V DC 3 A 15 W No. of outputs: 1 x Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 39.49 / piece)
€ 39.49
plus VAT.
Only 7 Piece(s) available
Technical specifications
- Product type
DC/DC converter (print)
- Type
THN 15-2411
- Nominal voltage
24 V DC
- Min. input voltage
18 V DC
- Input voltage (max.)
36 V DC
- No. of outputs
1 x
- Output voltages
5 V DC
- Max. output current
3 A
- Output current (max.) - rounded
3 A
- Efficiency (max.)
88 %
15 W
- Insulation voltage
1500 V DC
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
85 °C
- Dim
(L x W x H) 25.4 x 25.4 x 20.32 mm
- Height
20.32 mm
- Length
25.4 mm
- Width
25.4 mm
- Output voltage (max.)
5 V DC
- Output voltage (min.)
5 V DC
- Weight
15 g
- Content
1 pc(s)
- Type
THN 15-2411
Compliance & Certifications
Certified by EU Garan
Documents & Downloads
Datasheet
Datasheet 1510689 TracoPower THN 15-2411 DC/DC converter (print) 24 V DC 5 V DC 3 A 15 W No. of outputs: 1 x Content 1 pc(s)
Datasheet 1510689 TracoPower THN 15-2411 DC/DC converter (print) 24 V DC 5 V DC 3 A 15 W No. of outputs: 1 x Content 1 pc(s)
Warranty Terms
Warranty Terms 1510689 TracoPower THN 15-2411 DC/DC converter (print) 24 V DC 5 V DC 3 A 15 W No. of outputs: 1 x Content 1 pc(s)
Description
Ultra-compact dimensions: 25.4 mm x 25.4 mm x 10.2 mm, 2:1 input range, input/output insulation 1500 V/DC, external on/off, industry standard footprint.
