TracoPower THN 15-4812WIR DC/DC converter (print) 48 V DC +12 V DC 1.3 A 15 W No. of outputs: 1 x Content 1 pc(s)
Part number:
Item no:
Datasheet (PDF)
Number
Minimum order quantity: 10
Total (€ 53.77 / piece)
€ 537.70
plus VAT.
14-day return policy included
Technical specifications
- Product type
DC/DC converter (print)
- Type
THN 15-4812WIR
- Nominal voltage
48 V DC
- Min. input voltage
18 V DC
- Input voltage (max.)
75 V DC
- No. of outputs
1 x
- Output voltages
+12 V DC
- Max. output current
1.3 A
- Output current (max.) - rounded
1.3 A
- Efficiency (max.)
89 %
15 W
- Insulation voltage
3000 V DC
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
90 °C
- Dim
(L x W x H) 25.4 x 25.4 x 15.5 mm
- Height
15.5 mm
- Length
25.4 mm
- Width
25.4 mm
- Output voltage (max.)
12 V DC
- Output voltage (min.)
12 V DC
- Output current (min.)
0 mA
- Weight
16.5 g
- Content
1 pc(s)
Documents & Downloads
Datasheet
Datasheet 3371590 TracoPower THN 15-4812WIR DC/DC converter (print) 48 V DC +12 V DC 1.3 A 15 W No. of outputs: 1 x Content 1 pc(s)
Datasheet 3371590 TracoPower THN 15-4812WIR DC/DC converter (print) 48 V DC +12 V DC 1.3 A 15 W No. of outputs: 1 x Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3371590 TracoPower THN 15-4812WIR DC/DC converter (print) 48 V DC +12 V DC 1.3 A 15 W No. of outputs: 1 x Content 1 pc(s)
Warranty Terms
Warranty Terms 3371590 TracoPower THN 15-4812WIR DC/DC converter (print) 48 V DC +12 V DC 1.3 A 15 W No. of outputs: 1 x Content 1 pc(s)
Description
4:1 input range, according to EN 50155 and EN 61373 approvals for railways. Permanent short circuit and low-voltage cut-off, remote on/off. Output voltage can be set Input filter to EN 55011, class A.
