TracoPower THN 30-2412WIR DC/DC converter (print) 24 V DC 12 V DC 2.5 A 30 W No. of outputs: 1 x Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Minimum order quantity: 10
Total (€ 65.54 / piece)
€ 655.40
plus VAT.
14-day return policy included
Technical specifications
- Product type
DC/DC converter (print)
- Type
THN 30-2412WIR
- Nominal voltage
24 V DC
- Min. input voltage
9 V DC
- Input voltage (max.)
36 V DC
- No. of outputs
1 x
- Output voltages
12 V DC
- Max. output current
2.5 A
- Output current (max.) - rounded
2.5 A
30 W
- Connection
Soldering
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
+60 °C
- Dim
(L x W x H) 25.40 x 25.40 x 9.90 mm
- Height
9.90 mm
- Length
25.40 mm
- Width
25.40 mm
- RoHS-compliant
Yes
- Weight
18
- Content
1 pc(s)
