TracoPower THN 30-2425WIR DC/DC converter (print) 5 V DC 5 V DC, -5 V DC 625 mA 30 W No. of outputs: 2 x Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Minimum order quantity: 10
Total (€ 60.50 / piece)
€ 605.00
plus VAT.
14-day return policy included
Technical specifications
- Product type
DC/DC converter (print)
- Type
THN 30-2425WIR
- Nominal voltage
5 V DC
- Min. input voltage
9 V DC
- Input voltage (max.)
36 V DC
- No. of outputs
2 x
- Output voltages
5 V DC
-5 V DC
- Max. output current
625 mA
- Output current (max.) - rounded
625 mA
30 W
- Connection
Soldering
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
+60 °C
- Dim
(L x W x H) 25.40 x 25.40 x 9.90 mm
- Height
9.90 mm
- Length
25.40 mm
- Width
25.40 mm
- RoHS-compliant
Yes
- Weight
18
- Content
1 pc(s)
