TracoPower DC/DC converter (print) 48 V DC 3.3 V DC 7 A 30 W No. of outputs: 1 x Content 10 pc(s)
Item no:
Datasheet (PDF)
Total (€ 75.21 / piece)
€ 752.10
plus VAT.
14-day return policy included
Technical specifications
- Product type
DC/DC converter (print)
- Type
THN 30-4810WI
- Nominal voltage
48 V DC
- Min. input voltage
18 V DC
- Input voltage (max.)
75 V DC
- No. of outputs
1 x
- Output voltages
3.3 V DC
- Max. output current
7 A
- Output current (max.) - rounded
7 A
- Efficiency (max.)
87 %
30 W
- Insulation voltage
1500 V DC
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
80 °C
- Dim
(L x W x H) 25.4 x 25.4 x 20.32 mm
- Height
20.32 mm
- Length
25.4 mm
- Width
25.4 mm
- Output voltage (max.)
3.3 V DC
- Output voltage (min.)
3.3 V DC
- Weight
16.5 g
- Content
10 pc(s)
Documents & Downloads
Datasheet
Datasheet 2791908 TracoPower DC/DC converter (print) 48 V DC 3.3 V DC 7 A 30 W No. of outputs: 1 x Content 10 pc(s)
Datasheet 2791908 TracoPower DC/DC converter (print) 48 V DC 3.3 V DC 7 A 30 W No. of outputs: 1 x Content 10 pc(s)
User & Safety Instructions
User & Safety Instructions 2791908 TracoPower DC/DC converter (print) 48 V DC 3.3 V DC 7 A 30 W No. of outputs: 1 x Content 10 pc(s)
Warranty Terms
Warranty Terms 2791908 TracoPower DC/DC converter (print) 48 V DC 3.3 V DC 7 A 30 W No. of outputs: 1 x Content 10 pc(s)
Description
Ultra-compact dimensions: 25.4 mm x 25.4 mm x 10.2 mm, 4:1 input range, input/output insulation 1500 V/DC, external on/off, input filter according to EN 55022, class A.
