TracoPower THR 40-7222WI DC/DC converter (print) 110 V DC +12 V DC 1.67 A 40 W No. of outputs: 2 x Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Minimum order quantity: 10
Total (€ 73.94 / piece)
€ 739.40
plus VAT.
14-day return policy included
Technical specifications
- Product type
DC/DC converter (print)
- Type
THR 40-7222WI
- Nominal voltage
110 V DC
- Min. input voltage
36 V DC
- Input voltage (max.)
160 V DC
- No. of outputs
2 x
- Output voltages
+12 V DC
- Max. output current
1.67 A
- Output current (max.) - rounded
1.67 A
40 W
- Connection
Soldering
- Dim
(L x W x H) 50.80 x 25.40 x 11 mm
- Height
11 mm
- Length
50.80 mm
- Width
25.40 mm
- RoHS-compliant
Yes
- Weight
51.50
- Content
1 pc(s)
