TracoPower TIM 2-4813 DC/DC converter (print) 134 mA 2 W No. of outputs: 1 x Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
10
-
€ 29.40
30
4% = € 1.27
€ 28.13
Volume discounts vary depending on the seller
You save € 0.00
Number
Minimum order quantity: 10
Total (€ 29.40 / piece)
€ 294.00
plus VAT.
Technical specifications
- Product type
DC/DC converter (print)
- Type
TIM 2-4813
- Min. input voltage
9 V DC
- Input voltage (max.)
36 V DC
- No. of outputs
1 x
- Max. output current
134 mA
- Output current (max.) - rounded
134 mA
- Efficiency (max.)
82 %
2 W
- Insulation voltage
5000 V AC
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
95 °C
- Dim
(L x W x H) 24.30 x 14.40 x 10.20 mm
- Height
10.20 mm
- Length
24.30 mm
- Width
14.40 mm
- RoHS-compliant
Yes
- Output voltage (max.)
15.0 V DC
- Output voltage (min.)
15.0 V DC
- Weight
7 g
- Content
1 pc(s)
