Buy TracoPower TIW 24-124 SMPSU 24 V DC 1 A 24 W

A Traco Power electronic device, cylindrical in shape, with two protruding black cables; electronic component.

TracoPower TIW 24-124 SMPSU 24 V DC 1 A 24 W-1

1/2

Datasheet (PDF)

Fast track dispatch on Wed, 30 Sep

20 Piece(s)

Sales and shipping:

Conrad Electronic Terms & Conditions

Number

Piece(s)

Total (€ 58.82 / piece)

€ 58.82

plus VAT.

14-day return policy included

Report legal concerns

Highlights & Details

AC-DC power supply, 24 W, 24 V/1 A

High efficiency switching power supplies
Easy installation into standard flush boxes
Fully encapsulated plastic housing
Dust and waterproof to IP 67
Protection class ll
Safety approval to IEC/EN 60950-1 EN 50178 EN 60335-1 UL 1310 class 2
Universal input range 93 to 264 VAC
Regulated output voltage
Operating temp. range –25°C to +50°C
Short circuit and overload protection
3-year product warranty

Technical specifications

Input voltage range: 93-264 VAC
Output voltage: 24 VDC
Output current: 1 A
Power: 24 W
Efficiency: 85 %
Regulation: Input variation: 1 % max., Load variation (0-100%): 2 % max
Ripple and noise: <200 mVpk-pk (20 MHz bandwidth)
Short circuit protection: indefinite, automatic revovery (Foldback)
Operating temperature range:-25°C to +60°C

Product type: SMPSU

Input voltage (max.): 264 V AC

Max. output current: 1 A

Output current (max.) - rounded: 1 A

Min. input voltage: 90 V AC

Dim: (L x W x H) 63 x 56 x 32 mm

Output voltage (max.): 24 V DC

Connection: Open end cable

: 24 W

Type: closed

Weight: 100 g

Width: 56 mm

Height: 32 mm

Length: 63 mm

Type: TIW 24-124

Documents & Downloads

Datasheet

Datasheet 1083035 TracoPower TIW 24-124 SMPSU 24 V DC 1 A 24 W

User & Safety Instructions

User & Safety Instructions 1083035 TracoPower TIW 24-124 SMPSU 24 V DC 1 A 24 W

Warranty Terms

Warranty Terms 1083035 TracoPower TIW 24-124 SMPSU 24 V DC 1 A 24 W

Description

The TIW series is a new range of small size DC-power supplies which have been designed particularly for applications in home and office installations. The compact modules cases fit in the standardized in-wall flush boxes or also can be mounted on walls. For connection there are models available with flying wires The power supplies comply fully with the safety and EMC standards requested for commercial and residential class ll installations. Typical applications are powering of electric devices used in home automation and in security systems like i.e. DC-motors, controllers, indicators, etc.
