TracoPower TMA 1215D DC/DC converter (print) 12 V DC 15 V DC, -15 V DC 30 mA 1 W No. of outputs: 2 x Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 5.45
5
6% = € 0.32
€ 5.13
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 5.45 / piece)
€ 5.45
plus VAT.
Only 9 Piece(s) available
Highlights & Details
DC/DC converter TMA series, 1 W, SIL-7
- 3 year guarantee
- 100 % burn-in (8 hours)
Technical specifications
- Ripple: (20 MHz bandwidth) 75 mVpp
- Load regulation (%): ±10%
- Product type
DC/DC converter (print)
- Type
TMA 1215D
- Nominal voltage
12 V DC
- No. of outputs
2 x
- Output voltages
15 V DC
-15 V DC
- Max. output current
30 mA
- Output current (max.) - rounded
30 mA
- Efficiency (max.)
80 %
1 W
- Enclosure
SIL 7
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
85 °C
- Dim
(L x W x H) 19.5 x 7 x 10.2 mm
- Height
10.2 mm
- Length
19.5 mm
- Width
7 mm
- Content
1 pc(s)
1 W
- Output voltage
±15 V DC
- Output current (details)
±30 mA
- Type
TMA Series
- Operating temperature
-40 - +85 °C
- Mains control
(at 1 % variation Vin) max. ±1.2 %
Documents & Downloads
Datasheet
Datasheet 154265 TracoPower TMA 1215D DC/DC converter (print) 12 V DC 15 V DC, -15 V DC 30 mA 1 W No. of outputs: 2 x Content 1 pc(s)
Datasheet 154265 TracoPower TMA 1215D DC/DC converter (print) 12 V DC 15 V DC, -15 V DC 30 mA 1 W No. of outputs: 2 x Content 1 pc(s)
Warranty Terms
Warranty Terms 154265 TracoPower TMA 1215D DC/DC converter (print) 12 V DC 15 V DC, -15 V DC 30 mA 1 W No. of outputs: 2 x Content 1 pc(s)
Description
Industry-standard pinning.
Hints
Output voltage at rated load (unstabilized).
