TracoPower TMAP 1205S DC/DC converter (print) 200 mA 1 W No. of outputs: 1 x Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
10
-
€ 10.92
30
6% = € 0.61
€ 10.31
Volume discounts vary depending on the seller
You save € 0.00
Number
Minimum order quantity: 10
Total (€ 10.92 / piece)
€ 109.20
plus VAT.
14-day return policy included
Technical specifications
- Product type
DC/DC converter (print)
- Type
TMAP 1205S
- Min. input voltage
10.8 V DC
- Input voltage (max.)
13.20 V DC
- No. of outputs
1 x
- Max. output current
200 mA
- Output current (max.) - rounded
200 mA
- Efficiency (max.)
80 %
1 W
- Insulation voltage
3000 V DC
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
85 °C
- Dim
(L x W x H) 19.50 x 7.10 x 10.20 mm
- Height
10.20 mm
- Length
19.50 mm
- Width
7.10 mm
- RoHS-compliant
Yes
- Output voltage (max.)
5.0 V DC
- Output voltage (min.)
5.0 V DC
- Weight
3.10 g
- Content
1 pc(s)
Documents & Downloads
Datasheet
Datasheet 3372211 TracoPower TMAP 1205S DC/DC converter (print) 200 mA 1 W No. of outputs: 1 x Content 1 pc(s)
Datasheet 3372211 TracoPower TMAP 1205S DC/DC converter (print) 200 mA 1 W No. of outputs: 1 x Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3372211 TracoPower TMAP 1205S DC/DC converter (print) 200 mA 1 W No. of outputs: 1 x Content 1 pc(s)
