TracoPower TMDC 10-4823 DC/DC converter 333 mA 10 W No. of outputs: 2 x Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Minimum order quantity: 10
Total (€ 52.09 / piece)
€ 520.90
plus VAT.
14-day return policy included
Technical specifications
- Product type
DC/DC converter
- Type
TMDC 10-4823
- Min. input voltage
18 V DC
- Input voltage (max.)
75 V DC
- No. of outputs
2 x
- Max. output current
333 mA
- Output current (max.) - rounded
333 mA
- Efficiency (max.)
86 %
10 W
- Insulation voltage
3000 V DC
- Connection
Screw terminal
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
80 °C
- Dim
(L x W x H) 79 x 34 x 22 mm
- Height
22 mm
- Length
79 mm
- Width
34 mm
- RoHS-compliant
Yes
- Output voltage (max.)
15 V DC
-15 V DC
- Output voltage (min.)
15 V DC
-15 V DC
- Weight
65.80 g
- Content
1 pc(s)
- UKCA
yes
