TracoPower TMDC 10-7211H DC/DC converter 2 A 10 W No. of outputs: 1 x Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Minimum order quantity: 10
Total (€ 65.54 / piece)
€ 655.40
plus VAT.
14-day return policy included
Technical specifications
- Product type
DC/DC converter
- Type
TMDC 10-7211H
- Min. input voltage
80 V DC
- Input voltage (max.)
160 V DC
- No. of outputs
1 x
- Max. output current
2 A
- Output current (max.) - rounded
2 A
- Efficiency (max.)
83 %
10 W
- Insulation voltage
3000 V DC
- Connection
Screw terminal
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
70 °C
- Dim
(L x W x H) 79 x 34 x 22 mm
- Height
22 mm
- Length
79 mm
- Width
34 mm
- RoHS-compliant
Yes
- Output voltage (max.)
5.1 V DC
- Output voltage (min.)
5.1 V DC
- Weight
69 g
- Content
1 pc(s)
