TracoPower TMDC 20-4818 DC/DC converter (module) 48 V DC 48 V DC 420 mA 20 W No. of outputs: 1 x Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 65.54 / piece)
€ 65.54
plus VAT.
Only 1 Piece(s) available
Technical specifications
- Product type
DC/DC converter (module)
- Type
TMDC 20-4818
- Nominal voltage
48 V DC
- Min. input voltage
18 V DC
- Input voltage (max.)
75 V DC
- No. of outputs
1 x
- Output voltages
48 V DC
- Max. output current
420 mA
- Output current (max.) - rounded
420 mA
- Efficiency (max.)
89 %
20 W
- Insulation voltage
2500 V DC
- Connection
Screw terminal
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
90 °C
- Dim
(L x W x H) 54 x 96 x 23.3 mm
- Height
23.3 mm
- Length
54 mm
- Width
96 mm
- Output voltage (max.)
48 V DC
- Output voltage (min.)
48 V DC
- Weight
107 g
- Content
1 pc(s)
- Type
20-4818 TMDC
Compliance & Certifications
Certified by EU Garan
Documents & Downloads
Datasheet
Datasheet 1510808 TracoPower TMDC 20-4818 DC/DC converter (module) 48 V DC 48 V DC 420 mA 20 W No. of outputs: 1 x Content 1 pc(s)
Datasheet 1510808 TracoPower TMDC 20-4818 DC/DC converter (module) 48 V DC 48 V DC 420 mA 20 W No. of outputs: 1 x Content 1 pc(s)
Warranty Terms
Warranty Terms 1510808 TracoPower TMDC 20-4818 DC/DC converter (module) 48 V DC 48 V DC 420 mA 20 W No. of outputs: 1 x Content 1 pc(s)
Description
Vollverkapseltes, flat plastic casing, connection and fixing through screw terminal, 4:1 input voltage range. E/A-insulation 2500 V/DC, input filter according to EN 55022, class A, external on/off.
