TracoPower TME 0303S DC/DC converter (print) 3.3 V DC 3.3 V DC 260 mA 1 W No. of outputs: 1 x Content 1 pc(s)
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
10
-
€ 9.24
30
6% = € 0.53
€ 8.71
Volume discounts vary depending on the seller
You save € 0.00
Number
Minimum order quantity: 10
Total (€ 9.24 / piece)
€ 92.40
plus VAT.
Only 5 Piece(s) available
Technical specifications
- Product type
DC/DC converter (print)
- Type
TME 0303S
- Nominal voltage
3.3 V DC
- Min. input voltage
2.97 V DC
- Input voltage (max.)
3.63 V DC
- No. of outputs
1 x
- Output voltages
3.3 V DC
- Max. output current
260 mA
- Output current (max.) - rounded
260 mA
- Efficiency (max.)
74 %
1 W
- Insulation voltage
1000 V DC
- Enclosure
SIL 4
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
85 °C
- Dim
(L x W x H) 19.5 x 13.4 x 7.1 mm
- Height
7.1 mm
- Length
19.5 mm
- Width
13.4 mm
- Output voltage (max.)
3.3 V DC
- Output voltage (min.)
3.3 V DC
- Weight
2.6 g
- Content
1 pc(s)
Documents & Downloads
Datasheet
Datasheet 3371121 TracoPower TME 0303S DC/DC converter (print) 3.3 V DC 3.3 V DC 260 mA 1 W No. of outputs: 1 x Content 1 pc(s)
Datasheet 3371121 TracoPower TME 0303S DC/DC converter (print) 3.3 V DC 3.3 V DC 260 mA 1 W No. of outputs: 1 x Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3371121 TracoPower TME 0303S DC/DC converter (print) 3.3 V DC 3.3 V DC 260 mA 1 W No. of outputs: 1 x Content 1 pc(s)
Warranty Terms
Warranty Terms 3371121 TracoPower TME 0303S DC/DC converter (print) 3.3 V DC 3.3 V DC 260 mA 1 W No. of outputs: 1 x Content 1 pc(s)
Description
SIL-4 housing, unregulated output, input/output insulation 1000 V/DC, industry standard footprint.
