TracoPower TME 2412S DC/DC converter (print) 24 V DC 12 V DC 80 mA 1 W No. of outputs: 1 x Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
14 Piece(s)
Sales and shipping:
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 5.45
5
6% = € 0.32
€ 5.13
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 5.45 / piece)
€
Highlights & Details
DC/DC converter TME series, 1 W, SIL-4
- 3 year guarantee
Technical specifications
- Ripple: (20 MHz bandwidth) 150 mVpp
- Product type
DC/DC converter (print)
- Type
TME 2412S
- Nominal voltage
24 V DC
- No. of outputs
1 x
- Output voltages
12 V DC
- Max. output current
80 mA
- Output current (max.) - rounded
80 mA
1 W
- Enclosure
SIL 4
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
85 °C
- Dim
(L x W x H) 11.5 x 7 x 10.2 mm
- Height
10.2 mm
- Length
11.5 mm
- Width
7 mm
- Content
1 pc(s)
1 W
- Output voltage
12 V DC
- Output current (details)
80 mA
- Type
TME Series
- Operating temperature
-40 - +85 °C
- Mains control
(at 1 % variation Vin) max. ±1.2 %
Documents & Downloads
Datasheet
Datasheet 154503 TracoPower TME 2412S DC/DC converter (print) 24 V DC 12 V DC 80 mA 1 W No. of outputs: 1 x Content 1 pc(s)
Datasheet 154503 TracoPower TME 2412S DC/DC converter (print) 24 V DC 12 V DC 80 mA 1 W No. of outputs: 1 x Content 1 pc(s)
Warranty Terms
Warranty Terms 154503 TracoPower TME 2412S DC/DC converter (print) 24 V DC 12 V DC 80 mA 1 W No. of outputs: 1 x Content 1 pc(s)
Description
Hints
Output voltage at rated load (unstabilized).
