TracoPower TMF 30105 AC/DC PSU (print) 5 V DC 5 A 25 W
Part number:
Item no:
Datasheet (PDF)
Number
Minimum order quantity: 10
Total (€ 57.13 / piece)
€ 571.30
plus VAT.
Highlights & Details
AC/DC PCB power supply TracoPower TMF 30105 5 V/DC 5000 mA 25 W
- Output 5 V DC / 5 A
- Power 25 W
- Solder pins
Technical specifications
- Product type
AC/DC PSU (print)
- Input voltage (max.)
264 V AC
- Max. output current
5 A
- Output current (max.) - rounded
5 A
- Min. input voltage
90 V AC
- Dim
(L x W x H) 23.5 x 45.6 x 64.1 mm
- Output voltage (max.)
5 V DC
- Connection
Solder pins
25 W
- No. of outputs
1 x
- Type
closed
- Operating temperature (max.)
70 °C
- Max. operating temperature (derating)
50 °C
- Min. operating temperature (derating)
-25 °C
- Weight
135 g
- Width
45.6 mm
- Height
64.1 mm
- Length
23.5 mm
- Type
TMF 30105
Documents & Downloads
Datasheet
Datasheet 3371576 TracoPower TMF 30105 AC/DC PSU (print) 5 V DC 5 A 25 W
User & Safety Instructions
User & Safety Instructions 3371576 TracoPower TMF 30105 AC/DC PSU (print) 5 V DC 5 A 25 W
Warranty Terms
Warranty Terms 3371576 TracoPower TMF 30105 AC/DC PSU (print) 5 V DC 5 A 25 W
Description
Encapsulated power supplies with solder pins
Suitable for applications in medical technology
Safety standards according to IEC/EN/ES 60601-1 3rd Edition 2xMOPP
Protection class II in preparation
Protection against short-circuit, overload and voltage surges
This text is machine translated.
Suitable for applications in medical technology
Safety standards according to IEC/EN/ES 60601-1 3rd Edition 2xMOPP
Protection class II in preparation
Protection against short-circuit, overload and voltage surges
This text is machine translated.
