TracoPower TMH 1212D DC/DC converter (print) 12 V DC 12 V DC, -12 V DC 80 mA 2 W No. of outputs: 2 x Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 7.55
5
6% = € 0.46
€ 7.09
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 7.55 / piece)
€ 7.55
plus VAT.
Only 7 Piece(s) available
Highlights & Details
DC/DC converter TMH series, 2 W, SIL-7
- 3 years manufacturer's warranty
Technical specifications
- Control deviations: input change unregulated, last updated ±10 %
- Ripple: (20 MHz bandwidth) 75 mV pk-pk (5 V-input)/ 150 mV pk-pk (12/24 V-input)
- Product type
DC/DC converter (print)
- Type
TMH 1212D
- Nominal voltage
12 V DC
- No. of outputs
2 x
- Output voltages
12 V DC
-12 V DC
- Max. output current
80 mA
- Output current (max.) - rounded
80 mA
- Efficiency (max.)
82 %
2 W
- Insulation voltage
1000 V DC
- Enclosure
SIL
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
85 °C
- Dim
(L x W x H) 19.5 x 7.5 x 10.2 mm
- Height
10.2 mm
- Length
19.5 mm
- Width
7.5 mm
- Content
1 pc(s)
2 W
- Output voltage
±12 V DC
- Output current (details)
±80 mA
- Type
TMH 1212D
- Input voltage
12 V DC
- Efficiency
82 %
- Operating temperature
(above 70 ºC power reduction 3 %/K) -40 - +85 °C
- Insulation voltage
1000 V DC
Documents & Downloads
Datasheet
Datasheet 157187 TracoPower TMH 1212D DC/DC converter (print) 12 V DC 12 V DC, -12 V DC 80 mA 2 W No. of outputs: 2 x Content 1 pc(s)
Datasheet 157187 TracoPower TMH 1212D DC/DC converter (print) 12 V DC 12 V DC, -12 V DC 80 mA 2 W No. of outputs: 2 x Content 1 pc(s)
Warranty Terms
Warranty Terms 157187 TracoPower TMH 1212D DC/DC converter (print) 12 V DC 12 V DC, -12 V DC 80 mA 2 W No. of outputs: 2 x Content 1 pc(s)
Description
High degree of efficiency and industry standard pins.
Hints
Input voltage ± 10 %.
