TracoPower TMLM 04115 AC/DC PSU (print) 15 V DC 0.267 A 4 W
EAN:
Part number:
Item no:
Datasheet (PDF)
24 Piece(s)
Do your needs go beyond this?
Sales and shipping:
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 18.48
3
5% = € 0.92
€ 17.56
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 18.48 / piece)
€
Highlights & Details
TracoPower TMLM 04115 AC/DC PSU (print) 15 V DC 0.267 A 4 W
- Output 15 V DC / 0.267 A
- Power 4 W
- Solder pins
Technical specifications
- Max. output current
0.267 A
- Output current (max.) - rounded
267 mA
- Dim
(L x W x H) 37 x 27 x 17 mm
- Input frequency
47 - 440 Hz
- Output current 1
267 mA
- Height
17 mm
- Length
37 mm
- Width
27 mm
- Connection
Solder pins
- Type
TMLM 04115
- Type
Soldering pins
- Input voltage (max.)
264 V AC
- Min. input voltage
90 V AC
- Output voltage (max.)
15 V DC
4 W
4 W
- Output current (details)
267 mA
- Type
Synchronised
- Operating temperature
-25 to +60 °C
- Connection
Soldering pins
- Input voltage
90 - 264 V AC
- Output voltage 1
15 V
- Product type
AC/DC PSU (print)
Documents & Downloads
Datasheet
Datasheet 512615 TracoPower TMLM 04115 AC/DC PSU (print) 15 V DC 0.267 A 4 W
Datasheet 512615 TracoPower TMLM 04115 AC/DC PSU (print) 15 V DC 0.267 A 4 W
Warranty Terms
Warranty Terms 512615 TracoPower TMLM 04115 AC/DC PSU (print) 15 V DC 0.267 A 4 W
Description
AC/DC power supply modules of the TMLM series. Ultra-compact, fully cast switched-mode power supplies with the highest power density, which can be mounted directly on the circuit board. This makes these modules in an optimal solution for a variety of applications, where space is critical in the commercial and industrial electronics. International safety approvals, it is qualified for use worldwide. The structure in SMD technology and the high degree of efficiency guarantees a high degree of reliability of these switched-mode power supplies.
