TracoPower TMP 15115C SMPSU 15 V DC 1 A 15 W
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 52.09 / piece)
€ 52.09
plus VAT.
Only 2 Piece(s) available
Highlights & Details
TracoPower TMP 15115C SMPSU 15 V DC 1 A 15 W
- Ultra compact and flat
- AC- and DC-input
Technical specifications
- Product type
SMPSU
- Input voltage (max.)
264 V AC
- Max. output current
1 A
- Output current (max.) - rounded
1 A
- Min. input voltage
90 V AC
- Dim
(L x W x H) 23.3 x 54.0 x 96.0 mm
- Output voltage (max.)
15 V DC
- Connection
Screw terminal
15 W
- No. of outputs
1 x
- Type
closed
- Operating temperature (max.)
70 °C
- Max. operating temperature (derating)
50 °C
- Min. operating temperature (derating)
-25 °C
- Weight
162 g
- Type
Synchronised
- Width
54.0 mm
- Height
96.0 mm
- Length
23.3 mm
- Type
TMP 15115C
- Output current (min.)
0 mA
- Connection
Soldering pins
- Input voltage
90 - 264 V/AC/120 - 370 V DC
- Max. temperature
60 °C
- Min. temperature
-25 °C
Documents & Downloads
Datasheet
Datasheet 1591598 TracoPower TMP 15115C SMPSU 15 V DC 1 A 15 W
Datasheet 1591598 TracoPower TMP 15115C SMPSU 15 V DC 1 A 15 W
User & Safety Instructions
User & Safety Instructions 1591598 TracoPower TMP 15115C SMPSU 15 V DC 1 A 15 W
Warranty Terms
Warranty Terms 1591598 TracoPower TMP 15115C SMPSU 15 V DC 1 A 15 W
Description
Shed power supply module for PCB mounting with solder pins for chassis mounting with screw terminals. The module is designed for AC and DC capable operation TMPM version with ultra-compact design.
Features
- Short-circuit and overload protection
- Power limitation at: > 120-180% Inorm with foldback
- Safety standards / approvals: cUL / UL 60950-1, IEC / EN 60950-1, CB-Report
- Operating temperature: -25 to +60 ºC, derating>50 °C
- Housing as of UL 94V-0
