TracoPower TMP 30105C Power supply unit 6 A 30 W 5 V DC 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 72.26 / piece)
€ 72.26
plus VAT.
Only 3 Piece(s) available
Highlights & Details
Power supply module TMP 30105C
- No. of outputs: 1 x
- Output 1: 5 V DC / 6000 mA
- 30 W Power
- Synchronised
- Input voltage range 90 - 264 V/AC/120 - 370 V DC
- Connection (components): Solder pins
- Dimensions (L x W x H) 112 x 64 x 26 mm
- Ultra compact and flat
- AC- and DC-input
Technical specifications
- Product type
Power supply unit
- Input voltage (max.)
264 V AC
- Max. output current
6 A
- Output current (max.) - rounded
6 A
- Min. input voltage
90 V AC
- Dim
(L x W x H) 112 x 64 x 26 mm
- Output voltage (max.)
5 V DC
- Connection
Solder pins
30 W
- No. of outputs
1 x
- Output voltage 1
5 V DC
- Output current 1
6000 mA
- Type
closed
- Weight
191 g
- Type
Synchronised
- Width
64 mm
- Height
26 mm
- Length
112 mm
- Type
TMP 30105C
30 W
- Connection
Screw terminals
- Input voltage
90 - 264 V/AC/120 - 370 V DC
- Max. temperature
60 °C
- Min. temperature
-25 °C
Documents & Downloads
Datasheet
Datasheet 511978 TracoPower TMP 30105C Power supply unit 6 A 30 W 5 V DC 1 pc(s)
Datasheet 511978 TracoPower TMP 30105C Power supply unit 6 A 30 W 5 V DC 1 pc(s)
User & Safety Instructions
User & Safety Instructions 511978 TracoPower TMP 30105C Power supply unit 6 A 30 W 5 V DC 1 pc(s)
Warranty Terms
Warranty Terms 511978 TracoPower TMP 30105C Power supply unit 6 A 30 W 5 V DC 1 pc(s)
Description
Shed power supply module for chassis mounting with screw terminals. The module is designed for AC and DC capable operation
Features
- Short-circuit and overload protection
- Power limitation at: > 120-180% Inorm with foldback
- Safety standards / approvals: cUL / UL 60950-1, IEC / EN 60950-1, CB-Report
- Operating temperature: -25 to +60 ºC, derating>50 °C
- Housing as of UL 94V-0
