TracoPower TMP 30515C Power supply unit 5 V DC 3 A 30 W
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Minimum order quantity: 5
Total (€ 88.23 / piece)
€ 441.15
plus VAT.
Only 4 Piece(s) available
Highlights & Details
TracoPower TMP 30515C Power supply unit 5 V DC 3 A 30 W
- Ultra compact and flat
- AC- and DC-input
Technical specifications
- Product type
Power supply unit
- Input voltage (max.)
264 V AC
- Max. output current
3 A
- Output current (max.) - rounded
3 A
- Min. input voltage
90 V AC
- Dim
(L x W x H) 112 x 64 x 26 mm
- Output voltage (max.)
5 V DC
- Connection
Solder pins
30 W
- No. of outputs
3 x
- Type
closed
- Weight
191 g
- Type
Synchronised
- Width
64 mm
- Height
26 mm
- Length
112 mm
- Type
TMP 30515C
- Connection
Soldering pins
- Input voltage
90 - 264 V/AC/120 - 370 V DC
- Max. temperature
60 °C
- Min. temperature
-25 °C
Documents & Downloads
Datasheet
Datasheet 3369934 TracoPower TMP 30515C Power supply unit 5 V DC 3 A 30 W
Datasheet 3369934 TracoPower TMP 30515C Power supply unit 5 V DC 3 A 30 W
User & Safety Instructions
User & Safety Instructions 3369934 TracoPower TMP 30515C Power supply unit 5 V DC 3 A 30 W
Warranty Terms
Warranty Terms 3369934 TracoPower TMP 30515C Power supply unit 5 V DC 3 A 30 W
Description
Shed power supply module for PCB mounting with solder pins for chassis mounting with screw terminals. The module is designed for AC and DC capable operation TMPM version with ultra-compact design.
Features
- Short-circuit and overload protection
- Power limitation at: > 120-180% Inorm with foldback
- Safety standards / approvals: cUL / UL 60950-1, IEC / EN 60950-1, CB-Report
- Operating temperature: -25 to +60 ºC, derating>50 °C
- Housing as of UL 94V-0
