TracoPower TMPM 10124 Power supply unit 24 V DC 0.415 A 10 W
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 36.13 / piece)
€ 36.13
plus VAT.
Only 5 Piece(s) available
Highlights & Details
TracoPower TMPM 10124 Power supply unit 24 V DC 0.415 A 10 W
- 24 V DC
- 415 mA
- 10 W
- Ultra compact and flat
- AC- and DC-input
Technical specifications
- Product type
Power supply unit
- Input voltage (max.)
264 V AC
- Max. output current
0.415 A
- Output current (max.) - rounded
415 mA
- Min. input voltage
90 V AC
- Dim
(L x W x H) 53 x 28 x 24 mm
- Output voltage (max.)
24 V DC
- Connection
Solder pins
10 W
- No. of outputs
1 x
- Output voltage 1
24 V DC
- Output current 1
415 mA
- Type
closed
- Weight
54 g
- Type
Synchronised
- Width
28 mm
- Height
24 mm
- Length
53 mm
- Type
TMPM 10124
- MTBF
330000 h
10 W
- Connection
Soldering pins
- Input voltage
90 - 264 V/AC/120 - 370 V DC
- Max. temperature
60 °C
- Min. temperature
-25 °C
Compliance & Certifications
Certified by EU Garan
Documents & Downloads
Datasheet
Datasheet 512357 TracoPower TMPM 10124 Power supply unit 24 V DC 0.415 A 10 W
Datasheet 512357 TracoPower TMPM 10124 Power supply unit 24 V DC 0.415 A 10 W
User & Safety Instructions
User & Safety Instructions 512357 TracoPower TMPM 10124 Power supply unit 24 V DC 0.415 A 10 W
Warranty Terms
Warranty Terms 512357 TracoPower TMPM 10124 Power supply unit 24 V DC 0.415 A 10 W
Description
Shed power supply module for PCB mounting with solder pins. The module is designed for AC and DC capable operation TMPM version with ultra-compact design.
Features
- Short-circuit and overload protection
- Power limitation at: > 120-180% Inorm with foldback
- Safety standards / approvals: cUL / UL 60950-1, IEC / EN 60950-1, CB-Report
- Operating temperature: -25 to +60 ºC, derating>50 °C
- Housing as of UL 94V-0
