TracoPower TMPW 50-124-J SMPSU 24 V DC 2.08 A 50 W
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Minimum order quantity: 10
Total (€ 39.49 / piece)
€ 394.90
plus VAT.
Only 5 Piece(s) available
Highlights & Details
AC/DC switched-mode power supply, TMPW 50-J series
- Output 24 V DC / 2.08 A
- Power 50 W
- Jack connector
Technical specifications
- Product type
SMPSU
- Input voltage (max.)
305 V AC
- Max. output current
2.08 A
- Output current (max.) - rounded
2.08 A
- Min. input voltage
90 V AC
- Dim
(L x W x H) 97.0 x 48.3 x 25.4 mm
- Output voltage (max.)
24 V DC
- Connection
Jack connector
50 W
- No. of outputs
1 x
- Type
closed
- Operating temperature (max.)
70 °C
- Operating temperature (min.)
-40 °C
- Weight
180 g
- Width
48.3 mm
- Height
25.4 mm
- Length
97.0 mm
- Type
TMPW 50-124-J
- UKCA
yes
