TracoPower TMR 1-1222 DC/DC converter (print) 12 V DC 12 V DC, -12 V DC 42 mA 1 W No. of outputs: 2 x Content 1 pc(s)
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
10
-
€ 11.76
30
6% = € 0.65
€ 11.11
Volume discounts vary depending on the seller
You save € 0.00
Number
Minimum order quantity: 10
Total (€ 11.76 / piece)
€ 117.60
plus VAT.
14-day return policy included
Technical specifications
- Product type
DC/DC converter (print)
- Type
TMR 1-1222
- Nominal voltage
12 V DC
- Min. input voltage
9 V DC
- Input voltage (max.)
18 V DC
- No. of outputs
2 x
- Output voltages
12 V DC
-12 V DC
- Max. output current
42 mA
- Output current (max.) - rounded
42 mA
- Efficiency (max.)
79 %
1 W
- Insulation voltage
1500 V DC
- Enclosure
SIL 6
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
85 °C
- Dim
(L x W x H) 17 x 7.62 x 14.2 mm
- Height
14.2 mm
- Length
17 mm
- Width
7.62 mm
- Output voltage (max.)
12 V DC
-12 V DC
- Output voltage (min.)
12 V DC
-12 V DC
- Weight
3.1 g
- Content
1 pc(s)
Documents & Downloads
Datasheet
Datasheet 3372909 TracoPower TMR 1-1222 DC/DC converter (print) 12 V DC 12 V DC, -12 V DC 42 mA 1 W No. of outputs: 2 x Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3372909 TracoPower TMR 1-1222 DC/DC converter (print) 12 V DC 12 V DC, -12 V DC 42 mA 1 W No. of outputs: 2 x Content 1 pc(s)
Warranty Terms
Warranty Terms 3372909 TracoPower TMR 1-1222 DC/DC converter (print) 12 V DC 12 V DC, -12 V DC 42 mA 1 W No. of outputs: 2 x Content 1 pc(s)
Description
2:1 input range, compact SIL-6-casing, regulated output. Short-circuit protection, input/output insulation 1500 V/DC.
