TracoPower TMR 1-2415 DC/DC converter (print) 24 V DC 24 V DC 42 mA 1 W No. of outputs: 1 x Content 1 pc(s)
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
10
-
€ 10.92
30
6% = € 0.61
€ 10.31
Volume discounts vary depending on the seller
You save € 0.00
Number
Minimum order quantity: 10
Total (€ 10.92 / piece)
€ 109.20
plus VAT.
Technical specifications
- Product type
DC/DC converter (print)
- Type
TMR 1-2415
- Nominal voltage
24 V DC
- Min. input voltage
18 V DC
- Input voltage (max.)
36 V DC
- No. of outputs
1 x
- Output voltages
24 V DC
- Max. output current
42 mA
- Output current (max.) - rounded
42 mA
- Efficiency (max.)
77 %
1 W
- Insulation voltage
1500 V DC
- Enclosure
SIL 6
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
85 °C
- Dim
(L x W x H) 17 x 7.62 x 14.2 mm
- Height
14.2 mm
- Length
17 mm
- Width
7.62 mm
- Output voltage (max.)
24 V DC
- Output voltage (min.)
24 V DC
- Weight
3.1 g
- Content
1 pc(s)
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3371127 TracoPower TMR 1-2415 DC/DC converter (print) 24 V DC 24 V DC 42 mA 1 W No. of outputs: 1 x Content 1 pc(s)
Datasheet 3371127 TracoPower TMR 1-2415 DC/DC converter (print) 24 V DC 24 V DC 42 mA 1 W No. of outputs: 1 x Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3371127 TracoPower TMR 1-2415 DC/DC converter (print) 24 V DC 24 V DC 42 mA 1 W No. of outputs: 1 x Content 1 pc(s)
Warranty Terms
Warranty Terms 3371127 TracoPower TMR 1-2415 DC/DC converter (print) 24 V DC 24 V DC 42 mA 1 W No. of outputs: 1 x Content 1 pc(s)
Description
2:1 input range, compact SIL-6-casing, regulated output. Short-circuit protection, input/output insulation 1500 V/DC.
