TracoPower TMR 1-4812 DC/DC converter (print) 48 V DC 12 V DC 83 mA 1 W No. of outputs: 1 x Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 10.08
3
6% = € 0.58
€ 9.50
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 10.08 / piece)
€ 10.08
plus VAT.
Only 6 Piece(s) available
Technical specifications
- Product type
DC/DC converter (print)
- Type
TMR 1-4812
- Nominal voltage
48 V DC
- Min. input voltage
36 V DC
- Input voltage (max.)
75 V DC
- No. of outputs
1 x
- Output voltages
12 V DC
- Max. output current
83 mA
- Output current (max.) - rounded
83 mA
- Efficiency (max.)
80 %
1 W
- Insulation voltage
1500 V DC
- Enclosure
SIL 6
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
85 °C
- Dim
(L x W x H) 17 x 7.62 x 14.2 mm
- Height
14.2 mm
- Length
17 mm
- Width
7.62 mm
- Output voltage (max.)
12 V DC
- Output voltage (min.)
12 V DC
- Weight
3.1 g
- Content
1 pc(s)
- Type
TMR 1-4812
Documents & Downloads
Datasheet
Datasheet 1510863 TracoPower TMR 1-4812 DC/DC converter (print) 48 V DC 12 V DC 83 mA 1 W No. of outputs: 1 x Content 1 pc(s)
Datasheet 1510863 TracoPower TMR 1-4812 DC/DC converter (print) 48 V DC 12 V DC 83 mA 1 W No. of outputs: 1 x Content 1 pc(s)
Warranty Terms
Warranty Terms 1510863 TracoPower TMR 1-4812 DC/DC converter (print) 48 V DC 12 V DC 83 mA 1 W No. of outputs: 1 x Content 1 pc(s)
Description
2:1 input range, compact SIL-6-casing, regulated output. Short-circuit protection, input/output insulation 1500 V/DC.
