TracoPower TMR 3-2421WI DC/DC converter (print) 24 V DC 5 V DC, -5 V DC 300 mA 3 W No. of outputs: 2 x Content 1 pc(s)
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
10
-
€ 26.04
30
4% = € 1.13
€ 24.91
Volume discounts vary depending on the seller
You save € 0.00
Number
Minimum order quantity: 10
Total (€ 26.04 / piece)
€ 260.40
plus VAT.
Only 5 Piece(s) available
Technical specifications
- Product type
DC/DC converter (print)
- Type
TMR 3-2421WI
- Nominal voltage
24 V DC
- Min. input voltage
9 V DC
- Input voltage (max.)
36 V DC
- No. of outputs
2 x
- Output voltages
5 V DC
-5 V DC
- Max. output current
300 mA
- Output current (max.) - rounded
300 mA
- Efficiency (max.)
78 %
3 W
- Insulation voltage
1500 V DC
- Enclosure
SIL 8
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
85 °C
- Dim
(L x W x H) 21.8 x 9.2 x 11.1 mm
- Height
11.1 mm
- Length
21.8 mm
- Width
9.2 mm
- Content
1 pc(s)
3 W
- Type
TMR 3 Series
- Operating temperature
-40 - +85 °C
- Insulation voltage
1500 V DC
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3369943 TracoPower TMR 3-2421WI DC/DC converter (print) 24 V DC 5 V DC, -5 V DC 300 mA 3 W No. of outputs: 2 x Content 1 pc(s)
Datasheet 3369943 TracoPower TMR 3-2421WI DC/DC converter (print) 24 V DC 5 V DC, -5 V DC 300 mA 3 W No. of outputs: 2 x Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3369943 TracoPower TMR 3-2421WI DC/DC converter (print) 24 V DC 5 V DC, -5 V DC 300 mA 3 W No. of outputs: 2 x Content 1 pc(s)
Warranty Terms
Warranty Terms 3369943 TracoPower TMR 3-2421WI DC/DC converter (print) 24 V DC 5 V DC, -5 V DC 300 mA 3 W No. of outputs: 2 x Content 1 pc(s)
Description
The TMR-3WI 3 series offers insulated, regulated 3 Watt DC/DC-converter with an extended 4:1 input range. These modules placed in the compact SIL-8 plastic casing need an area of only 2 cm2 on the circuit board. The high degree of efficiency enables a working temperature range of –40 ° to +85 °C. Other features are the external on/off function and the short-circuit resistance. Owing to the ultra-compact dimensions this series offers an ideal solution for a number of applications, where space is critical and for battery-operated devices in industrial and communications systems.
