TracoPower TMR 6-4819 DC/DC converter (print) 48 V DC 9 V DC 666 mA 6 W No. of outputs: 1 x Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
10
-
€ 24.36
30
4% = € 1.06
€ 23.30
Volume discounts vary depending on the seller
You save € 0.00
Number
Minimum order quantity: 10
Total (€ 24.36 / piece)
€ 243.60
plus VAT.
Highlights & Details
DC/DC converter TMR 6 series
- Highest power density in the ultra-compact SIL-8 casing
- Wide 2:1 input ranges
- 6 watt converter with the smallest base area
- Surface-mounted using SMD technology
- Operating temperature range -40° to +65 °C.
- High efficiency
- Protected against permanent short circuit
- E/A-INSULATION 1500 VDC
- Remote on/off
- RoHS compliant
Technical specifications
- Control deviations: Input change: 0.2 % , load change (0-100%): 1.0 %
- Remaining ripple <50 mV pk-pk (20 MHz bandwidth)
- Short circuit protection: Continuous
- Safety standards UL/cUL 60950-1, IEC/EN 60950-1.
- Product type
DC/DC converter (print)
- Type
TMR 6-4819
- Nominal voltage
48 V DC
- Min. input voltage
36 V DC
- Input voltage (max.)
75 V DC
- No. of outputs
1 x
- Output voltages
9 V DC
- Max. output current
666 mA
- Output current (max.) - rounded
666 mA
- Efficiency (max.)
84 %
6 W
- Enclosure
SIL 8
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
65 °C
- Dim
(L x W x H) 9.1 x 21.8 x 15.3 mm
- Height
15.3 mm
- Length
9.1 mm
- Width
21.8 mm
- Weight
4.8 g
- Content
1 pc(s)
Documents & Downloads
Datasheet
Datasheet 3370090 TracoPower TMR 6-4819 DC/DC converter (print) 48 V DC 9 V DC 666 mA 6 W No. of outputs: 1 x Content 1 pc(s)
Datasheet 3370090 TracoPower TMR 6-4819 DC/DC converter (print) 48 V DC 9 V DC 666 mA 6 W No. of outputs: 1 x Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3370090 TracoPower TMR 6-4819 DC/DC converter (print) 48 V DC 9 V DC 666 mA 6 W No. of outputs: 1 x Content 1 pc(s)
Warranty Terms
Warranty Terms 3370090 TracoPower TMR 6-4819 DC/DC converter (print) 48 V DC 9 V DC 666 mA 6 W No. of outputs: 1 x Content 1 pc(s)
Description
The TMR-6 series offers insulated 6 watt DC/DC-converter with exactly regulated outputs and wide 2:1 input ranges. These ultra-compact converters with their SIL-8 plastic housings need a space of only 2.0 cm2 on the circuit board. The excellent degree of efficiency permits a working temperature range of –40° to +65°C. Other features are the external on/off function and the short-circuit resistance. Owing to the very compact dimensions this series offers the optimum solution for a number of applications in communication systems, measurement applications and industrial systems, where space is critical.
