TracoPower TMT 15115C AC/DC PSU (print) 15 V DC 1 A 15 W
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
TracoPower TMT 15115C AC/DC PSU (print) 15 V DC 1 A 15 W
- Output 15 V DC / 1 A
- Power 15 W
- Input voltage 85 - 264 V AC
- Screw terminal
Technical specifications
- Type
TMT 15115C
- Product type
AC/DC PSU (print)
- Input voltage (max.)
264 V AC
- Max. output current
1 A
- Output current (max.) - rounded
1 A
- Min. input voltage
85 V AC
- Dim
(L x W x H) 77 x 45 x 27 mm
- Output voltage (max.)
15 V DC
- Connection
Screw terminal
15 W
- Efficiency to
83 %
- Protection class
II
- No. of outputs
1 x
- Output voltage 1
15 V
- Output current 1
1 A
- Operating temperature
-25 to +60 °C
- Width
45 mm
- Height
27 mm
- Length
77 mm
- Residual ripple
< 150 mVss181812576
- Type
TMT 15115C
15 W
- Output rating
15 W
- Input voltage
85 - 264 V AC
- Connection
Screw terminals
- Input voltage
85 - 264 V AC
Documents & Downloads
Datasheet
Datasheet 512456 TracoPower TMT 15115C AC/DC PSU (print) 15 V DC 1 A 15 W
Datasheet 512456 TracoPower TMT 15115C AC/DC PSU (print) 15 V DC 1 A 15 W
User & Safety Instructions
User & Safety Instructions 512456 TracoPower TMT 15115C AC/DC PSU (print) 15 V DC 1 A 15 W
Warranty Terms
Warranty Terms 512456 TracoPower TMT 15115C AC/DC PSU (print) 15 V DC 1 A 15 W
Description
AC/DC-power supply module in cast plastic casing for chassis assembly using screw terminals. Wide-range input for worldwide usage. High degree of efficiency, low noise and low remaining ripple. Short-circuit and overload protection.
Features
- Current limitation: > 105% Inorm, Foldback
- According to EN 55022, class B and FCC, Level B. UL 94V-0. UL 1950, cUL/UL/IEC/EN 60950, UL/EN 60601-1.
Hints
Derating >40 °C.
