TracoPower TOP 60252 PSU 5 V DC 6 A 55 W
EAN:
Part number:
Item no:
Datasheet (PDF)
2 Piece(s)
Sales and shipping:
Number
Total (€ 48.73 / piece)
€
Only 2 Piece(s) available
Highlights & Details
AC/DC power supply, TOP-Series
- 60 W Open Frame Power Supply with high power density (base area 50.8 mm x 101.6 mm)
- Very high efficiency up to 88%
- Low leakage current
- Harmonic limits according to EN 61000-3-2
- Short circuit and overload protection
- This text is machine translated.
Technical specifications
- Product type
PSU
- Input voltage (max.)
264 V AC
- Max. output current
6 A
- Output current (max.) - rounded
6 A
- Min. input voltage
90 V AC
- Dim
(L x W x H) 30.0 x 50.8 x 101.6 mm
- Output voltage (max.)
5 V DC
- Connection
Connector
55 W
- No. of outputs
2 x
- Type
open
- Weight
205 g
- Width
50.8 mm
- Height
101.6 mm
- Length
30.0 mm
- Type
TOP 60252
- Output current 2 (max.)
3 A
- Output current 2 (min.)
0 A
- Output current (min.)
0 A
- Output voltage 2 (max.)
12 V DC
- Output voltage 2 (min.)
12 V DC
- Output voltage (min.)
5 V DC
- No. of inputs
1 x
- Max. temperature
70 °C
- Min. temperature
-10 °C
Documents & Downloads
Datasheet
Datasheet 1591633 TracoPower TOP 60252 PSU 5 V DC 6 A 55 W
Datasheet 1591633 TracoPower TOP 60252 PSU 5 V DC 6 A 55 W
Warranty Terms
Warranty Terms 1591633 TracoPower TOP 60252 PSU 5 V DC 6 A 55 W
