TracoPower TPI 100-115A-J PSU 15 V DC 6.67 A 100 W
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 82.34 / piece)
€ 82.34
plus VAT.
Only 6 Piece(s) available
Highlights & Details
AC/DC power supply, TPI series
- Output 15 V DC / 6.67 A
- Power 100 W
- Connector
Technical specifications
- Product type
PSU
- Input voltage (max.)
264 V AC
- Max. output current
6.67 A
- Output current (max.) - rounded
6.67 A
- Min. input voltage
85 V AC
- Dim
(L x W x H) 29.5 x 50.8 x 76.2 mm
- Output voltage (max.)
15 V DC
- Connection
Connector
100 W
- No. of outputs
1 x
- Type
open
- Weight
156 g
- Width
50.8 mm
- Height
76.2 mm
- Length
29.5 mm
- Type
TPI 100-115A-J
- Output current (min.)
0 A
- Output voltage (min.)
15 V DC
- No. of inputs
1 x
- Max. temperature
80 °C
- Min. temperature
-40 °C
