TracoPower TPP 65-231 PSU 15 V DC 4.34 A 65 W
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 105.03 / piece)
€ 105.03
plus VAT.
14-day return policy included
Highlights & Details
AC/DC power supply, TPP-series
- Output 15 V DC / 4.34 A
- Power 65 W
- Connector
Technical specifications
- Product type
PSU
- Input voltage (max.)
264 V AC
- Max. output current
4.34 A
- Output current (max.) - rounded
4.34 A
- Min. input voltage
85 V AC
- Dim
(L x W x H) 34.5 x 60.5 x 102.4 mm
- Output voltage (max.)
15 V DC
- Connection
Connector
65 W
- No. of outputs
2 x
- Type
open
- Weight
221 g
- Width
60.5 mm
- Height
102.4 mm
- Length
34.5 mm
- Type
TPP 65-231
- Output current 2 (max.)
6 A
- Output current 2 (min.)
0 A
- Output current (min.)
0 A
- Output voltage 2 (max.)
5 V DC
- Output voltage 2 (min.)
5 V DC
- Output voltage (min.)
15 V DC
- No. of inputs
1 x
- Max. temperature
85 °C
- Min. temperature
-40 °C
