TracoPower TRA 1-1223 DC/DC converter (print) 12 V DC 15 V DC, -15 V DC 34 mA 1 W No. of outputs: 2 x Content 1 pc(s)
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
10
-
€ 7.55
30
6% = € 0.46
€ 7.09
Volume discounts vary depending on the seller
You save € 0.00
Number
Minimum order quantity: 10
Total (€ 7.55 / piece)
€ 75.50
plus VAT.
Technical specifications
- Product type
DC/DC converter (print)
- Type
TRA 1-1223
- Nominal voltage
12 V DC
- Min. input voltage
10.8 V DC
- Input voltage (max.)
13.2 V DC
- No. of outputs
2 x
- Output voltages
15 V DC
-15 V DC
- Max. output current
34 mA
- Output current (max.) - rounded
34 mA
- Efficiency (max.)
87.5 %
1 W
- Insulation voltage
1000 V DC
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
85 °C
- Dim
(L x W x H) 19.5 x 13.4 x 7.1 mm
- Height
7.1 mm
- Length
19.5 mm
- Width
13.4 mm
- Output voltage (max.)
15 V DC
-15 V DC
- Output voltage (min.)
15 V DC
-15 V DC
- Weight
2.2 g
- Content
1 pc(s)
Documents & Downloads
Datasheet
Datasheet 3371459 TracoPower TRA 1-1223 DC/DC converter (print) 12 V DC 15 V DC, -15 V DC 34 mA 1 W No. of outputs: 2 x Content 1 pc(s)
Datasheet 3371459 TracoPower TRA 1-1223 DC/DC converter (print) 12 V DC 15 V DC, -15 V DC 34 mA 1 W No. of outputs: 2 x Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3371459 TracoPower TRA 1-1223 DC/DC converter (print) 12 V DC 15 V DC, -15 V DC 34 mA 1 W No. of outputs: 2 x Content 1 pc(s)
Warranty Terms
Warranty Terms 3371459 TracoPower TRA 1-1223 DC/DC converter (print) 12 V DC 15 V DC, -15 V DC 34 mA 1 W No. of outputs: 2 x Content 1 pc(s)
Description
Part regulated output (load), industry-standard pinning, E/A-insulation 1000 V/DC. Safe to operate up to 5000 m altitude.
