TracoPower TRI 20-2423 DC/DC converter (print) 670 mA 20 W No. of outputs: 2 x Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Minimum order quantity: 10
Total (€ 78.98 / piece)
€ 789.80
plus VAT.
14-day return policy included
Technical specifications
- Product type
DC/DC converter (print)
- Type
TRI 20-2423
- Min. input voltage
18 V DC
- Input voltage (max.)
36 V DC
- No. of outputs
2 x
- Max. output current
670 mA
- Output current (max.) - rounded
670 mA
- Efficiency (max.)
90 %
20 W
- Insulation voltage
4200 V AC
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
76 °C
- Dim
(L x W x H) 50.80 x 25.40 x 12 mm
- Height
12 mm
- Length
50.80 mm
- Width
25.40 mm
- RoHS-compliant
Yes
- Output voltage (max.)
15 V DC
-15 V DC
- Output voltage (min.)
15 V DC
-15 V DC
- Weight
30 g
- Content
1 pc(s)
