TracoPower TRN 1-4823 DC/DC converter (print) 48 V DC +15 V DC, -15 V DC 35 mA 1 W No. of outputs: 2 x Content 1 pc(s)
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
10
-
€ 12.60
30
6% = € 0.70
€ 11.90
Volume discounts vary depending on the seller
You save € 0.00
Number
Minimum order quantity: 10
Total (€ 12.60 / piece)
€ 126.00
plus VAT.
14-day return policy included
Technical specifications
- Product type
DC/DC converter (print)
- Type
TRN 1-4823
- Nominal voltage
48 V DC
- Min. input voltage
36 V DC
- Input voltage (max.)
75 V DC
- No. of outputs
2 x
- Output voltages
+15 V DC
-15 V DC
- Max. output current
35 mA
- Output current (max.) - rounded
35 mA
- Efficiency (max.)
79 %
1 W
- Insulation voltage
1600 V DC
- Enclosure
SIL
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
90 °C
- Dim
(L x W x H) 7.7 x 11.9 x 15.1 mm
- Height
15.1 mm
- Length
7.7 mm
- Width
11.9 mm
- Output voltage (max.)
15 V DC
-15 V DC
- Output voltage (min.)
15 V DC
-15 V DC
- Output current (min.)
0 mA
- Weight
2.1 g
- Content
1 pc(s)
- UKCA
yes
Compliance & Certifications
Certified by EU Garan
Documents & Downloads
Datasheet
Datasheet 3371630 TracoPower TRN 1-4823 DC/DC converter (print) 48 V DC +15 V DC, -15 V DC 35 mA 1 W No. of outputs: 2 x Content 1 pc(s)
Datasheet 3371630 TracoPower TRN 1-4823 DC/DC converter (print) 48 V DC +15 V DC, -15 V DC 35 mA 1 W No. of outputs: 2 x Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3371630 TracoPower TRN 1-4823 DC/DC converter (print) 48 V DC +15 V DC, -15 V DC 35 mA 1 W No. of outputs: 2 x Content 1 pc(s)
Warranty Terms
Warranty Terms 3371630 TracoPower TRN 1-4823 DC/DC converter (print) 48 V DC +15 V DC, -15 V DC 35 mA 1 W No. of outputs: 2 x Content 1 pc(s)
Description
Compact SIL-casing (11.9 mm x 7.7 mm x 11.0 mm), 2:1 input range. Exactly regulated output voltage, short-circuit proof.
