TracoPower DC/DC converter (print) 48 V DC +24 V DC 125 mA 3 W No. of outputs: 1 x Content 10 pc(s)
Item no:
Datasheet (PDF)
Total (€ 18.49 / piece)
€ 184.87
plus VAT.
14-day return policy included
Technical specifications
- Product type
DC/DC converter (print)
- Type
TRN 3-4815
- Nominal voltage
48 V DC
- Min. input voltage
36 V DC
- Input voltage (max.)
75 V DC
- No. of outputs
1 x
- Output voltages
+24 V DC
- Max. output current
125 mA
- Output current (max.) - rounded
125 mA
- Efficiency (max.)
82 %
3 W
- Insulation voltage
1600 V DC
- Enclosure
SIL
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
85 °C
- Dim
(L x W x H) 7.7 x 11.9 x 15.1 mm
- Height
15.1 mm
- Length
7.7 mm
- Width
11.9 mm
- Output voltage (max.)
24 V DC
- Output voltage (min.)
24 V DC
- Output current (min.)
0 mA
- Weight
2.1 g
- Content
10 pc(s)
Compliance & Certifications
Certified by EU Garan
Documents & Downloads
Datasheet
Datasheet 2792423 TracoPower DC/DC converter (print) 48 V DC +24 V DC 125 mA 3 W No. of outputs: 1 x Content 10 pc(s)
Datasheet 2792423 TracoPower DC/DC converter (print) 48 V DC +24 V DC 125 mA 3 W No. of outputs: 1 x Content 10 pc(s)
User & Safety Instructions
User & Safety Instructions 2792423 TracoPower DC/DC converter (print) 48 V DC +24 V DC 125 mA 3 W No. of outputs: 1 x Content 10 pc(s)
Warranty Terms
Warranty Terms 2792423 TracoPower DC/DC converter (print) 48 V DC +24 V DC 125 mA 3 W No. of outputs: 1 x Content 10 pc(s)
Description
Compact SIL-casing (11.9 mm x 7.7 mm x 11.0 mm), 2:1 input range. Exactly regulated output voltage, short-circuit proof.
