TracoPower TSP 600-136 Rail mounted PSU (DIN) 16500 mA 600 W No. of outputs:1 x Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
3 Piece(s)
Sales and shipping:
Number
Total (€ 410.92 / piece)
€
Only 3 Piece(s) available
Highlights & Details
AC/DC switching power supply, TSP series
- Robust design for harsh industrial environments
- For worldwide applications: Autorange input and int. Safety approvals
- ATEX and IECEx certification (extension -EX)
- Protection against short circuit,over voltage und overheating protection
- Adjustable output voltage:
- Shock and vibration-protected
- This text is machine translated.
Technical specifications
- Product type
Rail mounted PSU (DIN)
- Min. input voltage
85 V AC
- Input voltage (max.)
264 V AC
- Max. output current
16500 mA
- Output current (max.) - rounded
16.5 A
600 W
- No. of outputs
1 x
- Connection
Screw terminal
- Dim
(L x W x H) 130.0 x 165.0 x 125.0 mm
- Weight
2800 g
- Output voltage (max.)
+42.0 V DC
- Output voltage (min.)
+36.0 V DC
- Operating temperature (max.)
70 °C
- Min. operating temperature (derating)
40 °C
- Operating temperature (min.)
-25 °C
- Manufacturer part #
TSP 600-136
- Content
1 pc(s)
- Width
165.0 mm
- Height
125.0 mm
- Length
130.0 mm
- Max. temperature
70 °C
- Min. temperature
-25 °C
- Type
TSP 600-136
