TracoPower TSR 1-2433E DC/DC converter (print) 1 A 4 W No. of outputs: 1 x Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 4.03
5
7% = € 0.27
€ 3.76
10
9% = € 0.37
€ 3.66
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 4.03 / piece)
€ 4.03
plus VAT.
14-day return policy included
Technical specifications
- Product type
DC/DC converter (print)
- Type
TSR 1-2433E
- Min. input voltage
6 V DC
- Input voltage (max.)
36 V DC
- No. of outputs
1 x
- Max. output current
1 A
- Output current (max.) - rounded
1 A
- Efficiency (max.)
88 %
4 W
- Connection
Solder pins
- PSU features
DC-to-DC converter
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
85 °C
- Dim
(L x W x H) 11.6 x 7.5 x 10.2 mm
- Height
10.2 mm
- Length
11.6 mm
- Width
7.5 mm
- RoHS-compliant
Yes
- Output voltage (max.)
3.3 V DC
- Output voltage (min.)
3.3 V DC
- Weight
1.6 g
- Content
1 pc(s)
