TracoPower TSRN 1-2433SM DC/DC converter (SMD) 12 V DC 3.3 V DC 1 A No. of outputs: 1 x Content 1 pc(s)
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
10
-
€ 12.60
30
6% = € 0.70
€ 11.90
Volume discounts vary depending on the seller
You save € 0.00
Number
Minimum order quantity: 10
Total (€ 12.60 / piece)
€ 126.00
plus VAT.
14-day return policy included
Technical specifications
- Product type
DC/DC converter (SMD)
- Type
TSRN 1-2433SM
- Nominal voltage
12 V DC
- Min. input voltage
4.6 V DC
- Input voltage (max.)
42 V DC
- No. of outputs
1 x
- Output voltages
3.3 V DC
- Max. output current
1 A
- Output current (max.) - rounded
1 A
- Efficiency (max.)
87.5 %
- Enclosure
SMD
- Connection
SMD
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
85 °C
- Dim
(L x W x H) 15.2 x 11.8 x 7.6 mm
- Height
7.6 mm
- Length
15.2 mm
- Width
11.8 mm
- Output voltage (max.)
3.3 V DC
- Output voltage (min.)
3.3 V DC
- Weight
1.7 g
- Content
1 pc(s)
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3371501 TracoPower TSRN 1-2433SM DC/DC converter (SMD) 12 V DC 3.3 V DC 1 A No. of outputs: 1 x Content 1 pc(s)
Datasheet 3371501 TracoPower TSRN 1-2433SM DC/DC converter (SMD) 12 V DC 3.3 V DC 1 A No. of outputs: 1 x Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3371501 TracoPower TSRN 1-2433SM DC/DC converter (SMD) 12 V DC 3.3 V DC 1 A No. of outputs: 1 x Content 1 pc(s)
Warranty Terms
Warranty Terms 3371501 TracoPower TSRN 1-2433SM DC/DC converter (SMD) 12 V DC 3.3 V DC 1 A No. of outputs: 1 x Content 1 pc(s)
Description
Compact SMD casing, positive and negative output voltage, adjustable output voltage. No heat sink required, integrated filter capacitors, excellent behavior in the case of input and load change, short-circuit proof.
This text is machine translated.
This text is machine translated.
